EPG has developed a synchrophasor training portal to provide online training on synchrophasor technology and its use in operations.

Read More

A comprehensive platform that integrates synchrophasor-based state estimation and real-time wide area visualization technology to provide a state of the art synchrophasor monitoring platform.

Read More

Phasor Simulator for Operator Training (PSOT) is phasor based training simulator developed to train operators on the use of synchrophasor technology in real-time operations.

Read More

Customer Success Stories

Largest WAMS Deployment EPG Selected for World's Largest WAMS Deployment for GETCO

Electric Power Group (EPG) is pleased to share that it has been selected to supply GETCO in India with the world’s largest WAMS deployment. When completed in 2022, the system will be capable of receiving data from a record 1,650 PMUs at 50 samples per second. Key highlights include: 1. Partnership with Hitachi – ABB Power Grids (HAPG); EPG will be the sole supplier of the WAMS solution and HAPG will supply the PMUs and associated infrastructure. 2. Integrated and unified WAMS display with SCADA/EMS for enhanced situational awareness, real-time calculations and actionable intelligence for operators. 3. One-line diagrams with EMS/SCADA and PMU data. 4. Global monitoring of the WAMS IT infrastructure.
Click here for a press release describing the project

Gridsmarts ReportsNYISO tracks PMU performance with GridSmarts Reports

NYISO manages and tracks PMU performance through monthly reports from GridSmarts. Report includes overall PMU performance as well as breakdown of bad data for each PMU by error for use in data management business process.

Generator Model Validation (GMV)EPG Deploys Automated Generator Model Validation for PJM

With EPG's GMV, PJM can perform the required model validation using PMU data without having to take generator units offline.The model validation process is fully automated, performed in near-real time, and is triggered when events and system disturbances are detected to ensure models are accurate for real-time assessments.
Click here for more details on the deployment

eLSEPeak RC improves line impedance in its network model using EPG’s eLSE

The eLSE was used to identify and remediate faulty impedance values in their network model - used for traditional state estimation and contingency analysis. Peak RC is also using the eLSE for enhanced visibility beyond available PMUs; data conditioning and network model validation.

Oscillation DetectionPJM validates Oscillation Detection and Mode Meter Applications with Extensive Testing

The validation process was conducted using simulations, case studies, disturbance data, over a 6-month period. The testing has validated the algorithms used for oscillation detection and monitoring. PJM is now using the test results to develop operating guidelines.

RTDMS Mobile SolutionsSouthwest Power Pool (SPP) Utilizing RTDMS Mobile Solution

The mobile solution enables users to access RTDMS visualization through a web browser thereby offering a cost effective alternative to desktop software, with the added benefit of secure access on Android and iOS platforms.

About EPG

Electric Power Group, LLC (EPG) has been pioneering the development and deployment of synchro-phasor technologies since 2000. Our principals have extensive experience in running and managing utility grids, investigating root causes of major blackouts (WECC 1996, EI 2003), and leveraging this deep domain knowledge to develop industry leading synchrophasor technology applications for wide area real time monitoring, visualization and situational awareness. The EPG team has extensive hands-on experience with synchrophasor standards, networks, system architecture, deployments and performance analysis through work at EPG for leading ISO's and utilities including PJM, NYISO, ERCOT, CAISO, MISO, BPA, TVA, SCE, AEP, LADWP, SRP, Duke, Dominion, NYPA and other companies.
